1000L Conical Insulated Double Layer Dimple Jacket Stainless Steel 304/316 Isobaric Fermentation Tank Used for Restaurant/brewpub

1000L Stainless steel beer fermentation tank are mostly used in microbreweries.If you are starting a microbrewery or brewpub,the double wall stainless steel conical beer fermentation tank is necessory.These fermenters are designed to hold pressure so they can be used as bright beer tanks or uni-tanks.The fermenters are used both for fermenting and lagering.

The design of conical fermenters is based on our vast beer knowledges and especially the conical fermenter bottom and the fact that we combine fermentation and maturation in the same vessel is very important.They are professionally welded, pressure tested. So if you are looking for a quality made stainless tank which not only will produce high quality beer but also look great in your brewery then look no further.Conical bottom is convenient for recycling the yeast after finishing the fermenting.

Beer fermentation tank

Bright beer tank/service tank is restaurant/brewpub

Features of beer fermentation system

 Triple layer

1. Inside Skin (Mirror Polished)

2. Dimple Jacket (INCLUDING CONE)

3. 100mm PU Insulated Jacket (Brushed Finish)

Pressure Vessel
This is a unit tank design so the fermenter can be pressurised enabling you to use this not only as a fermenter but also a bright tank. Carbonate and dispense from the one vessel.

Shadowless Manway
- For easy cleaning and also for best results with CIP cleaning the shadowless manways are simply more sanitary and are the only way to go.

Beautifully Made/Pro Welded
- If you want a tank that not only performs great but is good looking enough to be the centrepiece of your bar, restaurant, or brewpub.

CIP Spray Ball
Geometrically designed to be effective with CIP.

4 Inch Tri-Clover Cap
This useful cap has 4inch tri-clover opening at the top which can be useful for dry hopping, late additoins, pitching of yeast and many other purposes.

Bunging Pressure Device

Sanitary bunging device with pressure gauge included. Fermentation pressure can be calibrated to obtain desired beer carbonation.

Sample Valve 1.5" TC

Heavy duty sample valve with large 3/8" pour spout. Body length 3-3/4" with 1.5" TC connection.

Vacuum & Pressure Relief Valve

Smaller pressure & vaccum relief valve, calibated at 15 psi of pressure.

Clamps&fittings

Stainless steel Tri-clamp

Sanitary Thermometer Well

Tri-clamp sanitary adapter for thermometer for fitting to tank ferrules.

Carbonation stone

Made from SS316 stainless steel, these stones have a submersible porous body that diffuses CO2 gas directly into brewing liquid. In an optimal system, the stone would be mounted to the lowest part of the tank to provide the longest distance for CO2 to travel to the head.

Rotating Racking Arms

Rotating racking arms are an integral part of any fermentation system. Typically found in the bottom cone of a cylindroconical fermentation tank, the racking arm is rotated slowly downward drawing off clear liquid until the fine sediment of yeast begins to trickle through.

carbonation stone and racking arm

Pressure relief valve&pressure gauge,side manhole

If you have interest in DEGONG beer brewing equipment,welcome to contact me freely
