Our high quality craft brewing equipment is 100% sanitary and made from premium 304 stainless steel, offering superior sanitation and easy cleaning.
Choose from a variety of conical fermenters, brew kettles, IBC totes, variable capacity tanks, mash tuns, hop backs, brite tanks, and other equipment for making quality Beer, Wine, Kombucha, Cider, Cold brew coffee and more. We have sizes for home brewing and commercial brewing systems, and can custom build any tank to fit your needs.
60 BBL Fermenter / Unitank (Jacketed with Side Manway)
3 zone jacketing on fermenters
This 60 bbl conical fermenter is rated to 2 Bar and features 3 zone jacketing in its cone and on the side wall. It was designed to provide superior performance and will provide optimum control of your fermentation process.
Material: Premium virgin 304 stainless steel
Total tank volume = 2,314 gallons
Features of this 60 bbl stainless steel fermenter:
Glycol Jacketed - 3 zones: Cone (x1) and sidewall (x2)
Shadowless manway for easy cleaning
Adjustable racking arm for clear transfer
Sample valve for quality testing
Back mount pressure gauge
Adjustable feet for leveling on uneven floors or fine height adjustments
Can easily be used to a Unitank
CIP arm and rotating CIP spray ball
(x2) Butterfly valves
Rated to 2 Bar (29 PSI rating)
Dimensions:
Tank material thickness = 3mm
Jacket and outer shell thickness = 2mm
Cone has 60 degree interior angle
Custom dimensions are no problem - just ask!
Side manway fermenters 20bbl
Customized 10bbl brewery equipment unitanks
