DGET-2000L
DGET
8438400000
What is a Brite Tank |
A Bright Tank is a dish-bottomed pressure-rated temperature-controlled tank used to hold beer in preparation for packaging. The term “bright” refers to “bright beer,” beer that has been rendered bright (clear) by filtration, centrifugation, fining, and/or maturation. In most breweries, beer will be filtered after leaving a uni-tank or lagering vessel and be directed into a bright tank. If the beer is to be force-carbonated, then the beer may be carbonated in-line, under pressure, between the fermenter or lagering tank and the bright tank. In this case, the beer should arrive at the bright tank with full carbonation.
| Brite Tank's Feature |
Service tanks, also called bright beer tanks, are the containers structurally identical to maturing tanks.Their typical feature is the certification for pressure 3.0 bar, since for their main function, which is filling the transport packaging ( kegs, bottles ) and draught beer ( in the adjacent restaurant ), it is necessary to keep beer under a higher pressure than is used in maturing tanks.
| Brite Tank's Specifications |
- All tanks are made of food grade stainless steel 304.
- Adopting advanced world famous brand components in electric parts and operation parts.
- Thickness: inner 3.0mm; out 2.0mm; jacket: 1.5mm
- Insulation: Polyurethane thickness: 100mm
- Working pressure: 1.5-2.0 bar Design pressure: 3.0 bar
- Cone 150° resist compression design
- Pressure controlled by pressure gauge automatically.
- 100% TIG welding with pure argon gas shield.
- Glycol jacket: dimpled plate on cone and side
- Heat exchange area: 2.69 square meter
- Interior surface: mirror polishing
- Exterior surface: oil bushed finish
- Interior full polished to Ra0.6µm without dead corner
- TC connected CIP arm with 360° coverage spraying ball
- Sanitary side mounted manhole with pressured door
- Main accessories: mechanical type safety valve, sampling valve, pressure gauge, temperature probe, racking arm, leveling tube, solenoid valve, etc...
| Brite Tank's Application |
The cylindrical storage tank for final work with purified beverage (called also serving tank, filling tank, service tank, storage tank, BBT – Bright beer tank) . This type of the beverage-production tank is equipped with a horizontal stackable construction. This professional equipment is designed to storage, serving, carbonization, filtration of beer, cider, wine and other beverages under pressure, and also for preparation of beverages before their filling into kegs or bottles. The vessel is available in several variants, it is made of food grade steel AISI 304.The tank is normally available in several versions (optional dimensions, quality class, maximum pressure). All parts are made in European Union.
| Service |
