| Thickness of material (mm): | |
|---|---|
| Insulation: | |
| Material: | |
| Fermentation tank coolinig: | |
| Certificate: | |
| Quantity: | |
DGET-6BBL
DGET
8438400000
Without any dead corner
Discharge with rotation
Multi-stage cooling jacket can save more energy
Various heating methods (electric heating, gas heating, steam heating)
Filter plate (unique design with back taper)
Churn (manual, semi-automatic, top stirrer and bottom stirrer)
Our equipment is mainly used in brewing of beer, stout and rum. Besides, the product made by our equipment is tasty and fragrant.
1. The inner of the fermentation tank are adopted 304 stainless steel. Use polyurethane to keep warm. The outside scarfskin is according to the customer's requirement. You can choose stainless steel polishing, carbon steel, spray finishing and so on.
2.Adopted the international standard of fermentation technology, diverse methods to control the temperature. The inner surface of the tank is mirror-polished. The standard is 0.4um. Completely meet the demand of PLC and sterilize system.
3.The cooling jacket can achieve all countries standard, supply Miller, arch, corrugated plate and so on. Meet all kinds of demand of cooling technology of coolant and pressure.
Dished head and 60degree cone bottom
CO2 blow-off arm with butterfly valves
Sanitary top mounted pressure manway
CIP arm with 360° coverage CIP spraying ball
PT100, solenoid valve, single tank single control
Fermentation heat exchanger area: 2.95㎡
content gauge (Stailess stee shell and glass tube with liquid level valve)
Exterior welding seams brushed sand belt, welding points to be acid passivated.
3 heavy duty stainless steel legs with leveling footpads
All inwall polishing, acid picking and passivation.
sample valve, breather valve, cabonation stone, mechanical regulator valve, raking arm
the parts of conical beer fermenter
1.About the raw material:
All tanks are made of international standard stainless steel, we use 3mm interior shell and 2mm exterior shell.
2.About the drawing:
Generally our technician will design the suitable layout accordingly before production once our customers confirmed their orders.
Then our workshop will do the manufacturing strictly according to the detailed drawing. It is normative for every order.
3.About the welding and polishing:
We make sure the 100% TIG welding with pure argon gas shield. We use the central system of argon, instead of ordinary gas cylinder.
The argon will help to reduce the oxygenation. After welding, they will be polished to arrive to 0.4 μm without dead corner firstly, then do acid pickling and passivation.
Which will help to remove the oxygenation on welding line; and form protection film on the steel to avoid rust. It will help you to extend the tanks life time.
the beermaster is adding hops
welding tanks details
If you are interested in beer fermenter, get in touch with me freely.
Without any dead corner
Discharge with rotation
Multi-stage cooling jacket can save more energy
Various heating methods (electric heating, gas heating, steam heating)
Filter plate (unique design with back taper)
Churn (manual, semi-automatic, top stirrer and bottom stirrer)
Our equipment is mainly used in brewing of beer, stout and rum. Besides, the product made by our equipment is tasty and fragrant.
1. The inner of the fermentation tank are adopted 304 stainless steel. Use polyurethane to keep warm. The outside scarfskin is according to the customer's requirement. You can choose stainless steel polishing, carbon steel, spray finishing and so on.
2.Adopted the international standard of fermentation technology, diverse methods to control the temperature. The inner surface of the tank is mirror-polished. The standard is 0.4um. Completely meet the demand of PLC and sterilize system.
3.The cooling jacket can achieve all countries standard, supply Miller, arch, corrugated plate and so on. Meet all kinds of demand of cooling technology of coolant and pressure.
Dished head and 60degree cone bottom
CO2 blow-off arm with butterfly valves
Sanitary top mounted pressure manway
CIP arm with 360° coverage CIP spraying ball
PT100, solenoid valve, single tank single control
Fermentation heat exchanger area: 2.95㎡
content gauge (Stailess stee shell and glass tube with liquid level valve)
Exterior welding seams brushed sand belt, welding points to be acid passivated.
3 heavy duty stainless steel legs with leveling footpads
All inwall polishing, acid picking and passivation.
sample valve, breather valve, cabonation stone, mechanical regulator valve, raking arm
the parts of conical beer fermenter
1.About the raw material:
All tanks are made of international standard stainless steel, we use 3mm interior shell and 2mm exterior shell.
2.About the drawing:
Generally our technician will design the suitable layout accordingly before production once our customers confirmed their orders.
Then our workshop will do the manufacturing strictly according to the detailed drawing. It is normative for every order.
3.About the welding and polishing:
We make sure the 100% TIG welding with pure argon gas shield. We use the central system of argon, instead of ordinary gas cylinder.
The argon will help to reduce the oxygenation. After welding, they will be polished to arrive to 0.4 μm without dead corner firstly, then do acid pickling and passivation.
Which will help to remove the oxygenation on welding line; and form protection film on the steel to avoid rust. It will help you to extend the tanks life time.
the beermaster is adding hops
welding tanks details
If you are interested in beer fermenter, get in touch with me freely.
