Beer brewing equipment are usually independently owned. Such breweries are generally characterized by theire empahsis on flavor and brewing technique. We supply microbreweries from 500L to 3500L per brew. Our service includes:complete microbrewery equipment, installation, recipes of branded beers, staff training etc. If necessary, it can be expanded in future.
Complete beer brewing equipment for microbreweries with production of 1500L of beer per batch. Our 1000L brewery equipment is custom-made specially composed brewhouses are manufactured on customer's request. Our brewing equipment enables production of all styles of beer. All brewing operations as well as fermenting & conditioning process can be controlled via semi-automatic-control with programming system, or can be fully automatic (computer controlled) depending on customer's requirements. Hereby I am going to describe some info of brewhouse and fermentation system for you.
|Standard configuration of brewery equipment|
1. Mashing tun / Boiling tun: Use steam heat method, with designed jacket and agitation device to ensure the heating rate while avoiding coking, saving steam.
2. Lauter tun / Whirlpool tun: Easy assembly, with detachable combination of rake and sieve plate to achieve better stirring. Increase the diameter of the central cylinder to improve the effect of stirring and drain rate. The wort outlet is designed according to dynamics which enables the collection of wort to be faster and more homogeneous.
3. We can provide customization according to different design: 2 vessels(mash tun with lauter tun and boiling tun with whirlpool tun) 3 vessels (mash tun, lautering tun and boiling tun with whirlpool; Or mash tun with lautering, boiling tun and whirlpool tun), or separate 4 vessels combination.
4. All tanks are manufactured by SUS304/316, with an inner polish of less than 0.4µm and outer polish of less than 0.8µm.
100% TIG welded with argon gas protection
Stainless steel 304 sanitary construction
Design pressure: 0.3MPa, working pressure: 0.15-0.2MPa
Interior shell: thickness 3.0mm, mirror polished
Exterior shell: thickness 2.0mm, 2B-Pickled
Dimple jacket: thickness 1.5mm
4 heavy duty stainless steel legs with leveling foodpads
Dual cooling zones on the cylinder and cone
Vacuum valve/ PVRV
SS CIP spraying all with 360° of coverage
Dry hopping hole
Carbonation stone well reserved
1)Help the clients to confirm the configuration list
2)Supplying different beer craft specification
3)Designing the drawing according to the client's floor plan and your requirement
4)Showing the detailed diagram of the tanks
1)We provide turnkey system, onsite installation service for brewery projects.
2)It's available for us to send engineers to guide install
3)Life time guarantee
4)Online technology consult
|Why choose us|
1.Advanced German beer technology,equipped with industry-leading of equipment.
2.Dedicated and well trained marketing team of consulting services to customers before they make decisions.
3.Professional team of engineers for project design, equipment selection, which make sure that the brewery system are up to customers' satisfaction.
4.Professional team of project engineers, who are responsible for system installation, commissioning and all after-sales technical support.
5.Complete quality control and management systems.
