1000L Copper Pot Stills Commercial Distillation Equipment Copper Alcohol Distillation Column for Any Types Distillation Spirits

Distillation equipment is the result of continuous innovating and developing based on our experience of brewery equipment manufacturing. DEGONG distillation equipment can be used to make fruit wine, whiskey, vodka, gin, tequila, rum, brandy and other distilled spirits.

The 1000L distilling equipment is a very high quality with a lower price. The still is turnkey and complete with control panel, agitator and CIP system. The still is capable of making anything including flavored spirits, as well as vodka & gin.

Still pot

Dimension:top Ф1100*350,bottom Ф1100*600

Structure:dish top and bottom,Ф51 outlet,with agitator,

UL certified explosion proof agitator motor

Power: 1.1kw/120 rpm

Thickness of inner tank/jacket/cladding:5/4/2 mm

Material: Dish head is copper, other parts made of SS 304

Onion Dome

Material:copper

Thickness: 3mm

Flange:Ф600

Gin basket

Dimension:300 x 500 mm

Thickness: 3 mm

Material: SS304/Glass/Copper

Structure: manway in hook quick-open style, detachable

filter screen barrel in the tank

Distillation column

Dimension:350 x 2000 x 1

Thickness: 3mm

Material: copper,without welding line

Accessory: CIP spray ball, 8 block tower plate 18 unit Ф45

bubble cap

Dephlegmator

Material: T2 red copper

Thickness: 3mm

Style:column-tube type heat exchanger

Condensation area: 2m2

Rectification Column

Dimension:450 x 1900 x 1, 450 x 1000 x 1

Thickness: 3 mm

Material: T2 red copper,without welding line

Accessory:CIP spray ball, 8 block tower plate;18 unit Ф45

bubble cap

Dephlegmator

Material:T2 red copper

Thickness: 3 mm

Style:column-tube type heat exchanger

Condensation area:2m2

If you have interest,welcome to contact me freely
