DGET-1000L
DGET
8438400000
DEGONG custom design and engineer each piece of equipment for industrial use.DEGONG distilling equipment can make any type alcohol,such as whiskey, rum,brandy,gin,rum brandy and other types distilled liquor.All systems is automatic controled,easy assembly and convenient operation.Can be used in worksops,hotel,restaurant......
Pot Still:
1. Material: stainless steel/ red copper / stainless steel with red copper
2.Assembled with agitator
Column:
1.Material: copper/ stainless steel
2.Reflux control valve
3.Sight glass, CIP and thermometer at every plate.
4. Material of condenser: stainless steel/red copper/stainless still with red copper
Working Capacity: 1000L
Upper copper inner pot with SUS304 jacket & PU foam insulation
Steam heating without control box
Power consumption: 100kg/h steam heating (or 6*10kw electric heaters)
Agitator: 1.1kw motor, explosion proof with UL & CSA & CE approved
Copper helemt: mushroom shape (also have other shape for choice)
Glass Gin basket: inner with copper basket
14 inch / 350mm Copper column: 4 Plates + 16 Plates
SUS304 Dephlegmator : shell and tube type
SUS304 Condenser : shell and tube type
SUS304 Parrot with glass proof
SUS304 CIP system: CIP ball & no-return ball, CIP pipe, CIP pump
Bypass system: from pot to condenser / from pot to gin basket to condenser / from pot to column to condenser. etc.
Whisky Distiller | 50-5000L | Still pot,Swan neck,Condenser,Cip,Pipe system |
Vodka Distiller | 50-5000L | Still pot,Onion head,Column,Dephlegmater,Condenser,Pipe system |
Brandy Distiller | 50-5000L | Still pot,Onion head,Column,Dephlegmater,Condenser,Pipe system |
Rum Distiller | 50-5000L | Still pot,Column,Condenser,Cip,Pipe system |
Gin Distiller | 50-5000L | Still pot,Column,Gin basket,Condenser,Cip,Pipe system |
Multi-Function Distiller | 50-5000L | Still pot,Column,Onion head,Dephlegmater,Gin basket,Condenser,Cip,Pipe system,Collecting tank |
If you have interest,welcome to contact me freely
