Conical Fermenter 5bbl-20bbl used for restaurant and brewpub fermenting vessel/unitanks
Home » Brewery Equipment » Beer brewery equipment » Conical Fermenter 5bbl-20bbl used for restaurant and brewpub fermenting vessel/unitanks

Product Detail

Share to:

Conical Fermenter 5bbl-20bbl used for restaurant and brewpub fermenting vessel/unitanks

Our conical fermenters between 1 and 100 bbl are made at a family owned manufacturer in China. The premium beer brewing tanks come from DEGONG.Our tanks are designed by our designer. Cleanability, ease of use, and durability are our primary design criteria.
Thickness of material (mm):
Material:
Heating source:
Quantity:
  • DGET-5BBL
  • DGET
  • 8438400000

5bbl conical fermenters/unitanks

Conical fermenters are very well constructed and represent an amazing overall value. They also boast a very impressive feature set.


Great Quality & Great Value

Our conical fermenters between 1 and 100 bbl are made at a family owned manufacturer in China. The premium beer brewing tanks come from  DEGONG.Our tanks are designed by our designer. Cleanability, ease of use, and durability are our primary design criteria.We have a great price and we pass that on to you.

 fermenters

Customized beer fermenters/unitanks 1bbl minimum size


Impressive Features

Built from quality-checked 304 stainless steel, our tanks boast a hefty list of features. Here are some key features that are not always included on all tanks.

100mm of internal insulation between tank and outter jacket when the industry standard is 80mm

Separate cone and tank cooling jackets with individual Pt100 Thermocouples

DIN Rotating racking arm for safety and ease of use

4'' TC top hop port with handle

Carbonation Stone included with all tanks

Bottom valve for easier trub removal

CIP spinning spray ball and piping built-in

25% head-space above stated volume

Industry standard 2b finish



side manhole FV-min

5bbl/10bbl/20bbl popular size fermenters


All Features:

304 stainless steel construction

The outer shell is 2 mm thick with a brushed finish

The inner wall is 3 mm thick with smooth ground welds, 2B finish and passivated

Includes a glycol jacket which is dimple welded and 1.5 mm thick

Oversized for 25% average headspace

Pressure Relief/Vacuum Breaker valve

2x Pt100 Thermocouple interfaces at top and bottom

Perlick style sample valve

Spinning CIP cleaning head and separate piping

Rotating racking arm upgraded with DIN fitting for increased reliability

Temperature gauge

Oversized yeast dump port

Sealed Pressure Gauge

Hop port

Carb stone

Separate blow-off pipe

Side man-door

Shadowless Manway

Ladder for lager size tanks



fermenters 详情-min

Same size or double size of brewhouse


dished drain outlet legs-min

Dished head,discharge,heavy legs



Specifications for 5 bbl Conical:

can customize the size of unitanks/fermenters

Food grade 304 Stainless Steel

Internal Finish: Polished #2B

Working Pressure: 1.5 Bar

All ports are existing, Hopping Port,CIP Port,PVRV, Drain Outlet,  Pressure Gauge,Rotating Racking arm, and Glycol Ports


taproom-min
