DEGT-300L
DEGT
8438400000
300L Brewery System is between home brew and microbrewery equipment according to the capacity, it is a set of technological equipment for the production of heavy feeling craft beer. Because of its affordable cost and limited space requirement, It is really a good springboard for brewers to realize their brewing dreams further by sell beer to market. By Brewery System, Brew master make their beer attractive to consumers by unique brewing process and distinctive beer favor.
300L fermentation tanks
Heating method: steam heating, eletric heating, direct fire heating
Mash/Lauter tun
Material:Inner(SUS304）TH=3.0mm,
Jacket(SUS)304,TH=3.0mm
Cylinder(sharp type,SUS304),TH=3.0mm
Inner surface treatment:welds grinded to 0.6μm。
Insulation:Polyurethane-thickness 80mm
Temperature way:Double matal thermometer
Outsourcing surface:Weld polishing processing
Jacket Pressure:design pressure 0.3MPa,working pressure <0.2MPa.
CIP 360 degrees Omni bearing cleaning
Boiling/Whirlpool tun
Material:Inner(SUS304）TH=3.0mm,
Jacket(SUS)304,TH=3.0mm
Cylinder(sharp type,SUS304),TH=3.0mm
Inner surface treatment:welds grinded to 0.6μm。
Insulation:Polyurethane-thickness 80mm
Temperature way:Double matal thermometer
Outsourcing surface:Weld polishing processing
Jacket Pressure:design pressure 0.3MPa,working pressure <0.2MPa.
CIP 360 degrees Omni bearing cleaning
Bottom and side jacket, temperature probe
Top glass manhole
Control box
Plate heat exchanger: 5㎡, Two stages, Stainless steel 304
YUY pump: ABB motor, VFD control, Stainless steel 304
Fermentation tank
Interior Shell: SUS304 full welded; TH=3mm
Exterior Shell:SUS304 full welded; TH=2mm
100% TIG welding with pure argon gas shield
Interior Finish: Overall polishing to 0.6 μm without dead corner
Insulation: Polyurethane; TH=80mm
Dimple cooling jacket on cone and bottom
Top manway
60 degree cone bottom
Perlick style full sanitary sampling valve
Carbonation port and level tube for special request
Bright beer tank
150 degree cone bottom
Dimple cooling jacket on cone and bottom
Level tube for checking
Top manway
Perlick style full sanitary sampling valve
Carbonation port with tri clmap carbonation stone
300L bright beer tanks
Brewing process
Brewhouse unit details
Fermentation tank details
If you want to order beer brewery equipment, please contact with me.
