custom 10HL-100HL food grade beer equipment craft brewery best brew systems to buy

Nano brewery equipment widely used in hotel ,pub, restaurant
its occupying small space also easy operation
Material with top quality ; fully automatic touch screen on the whole fermentation process and mash process
Thickness of material (mm):
Yield:
heating method:
Availability:
Quantity:
  • DEGONG-10hl-100hl
  • DEGONG
  • 8438400000

 2 Vessel Brew House



Mash /Lauter Tun

Fully Tig welded – no rivets – double skinned with 80-100mm insulation

Infusion mash – so no raker

Not heated – but steam heating jackets can be fitted at extra cost

Side mounted grain shute and top manway

False bottom and Underback/Grant

With combined Lauter rakes and grain emptying plough.


Kettle Whirlpool

Fully Tig welded – no rivets – double skinned with 80-100mm insulation

Tangential inlets to initiate whirlpool and vortex breaker

Steam heated (electrical possible) using Steam jacket on jacket and cone

Mashing Agitator available at extra cost

brewhouse32

Compact 2 vessel brewhouse systems

Also includes

Sanitary Brewing pump with speed control

Sanitary Brewing pump with speed control

Non slip Work platform

Wort oxygenation and yeast adding tank

Pt100 Temperature sensors

IFM flow sensors for Hot Liquor and Wort


3 Vessel Brew House



Mash /Lauter Tun

Fully Tig welded – no rivets – double skinned with 80-100mm insulation

Not heated – but steam heating jackets can be fitted at extra cost

Side mounted grain shute and top manway

False bottom and Underback/Grant

With combined Lauter rakes and grain emptying plough.


Kettle

Fully Tig welded – no rivets – double skinned with 80-100mm insulation

Steam Heated with 2 jackets on the side and 1 on the bottom.

Top Glass manway with LED lighting


Whirlpool

Tangential inlets to initiate whirlpool and vortex breaker

Top Manway and LED lighting

Tubular heat exchanger available at extra cost.

brewhouse33

1000-2000L 3 vessel brewhouse sytem with Non slip Work platform


Also includes

Sanitary Brewing pump with speed control

Stainless steel transfer Plate Heat Exchanger on triclamp fittings

Non slip Work platform

Wort oxygenation and yeast adding tank.

Pt100 Temperature sensors on Mash, Kettle and Whirlpool

IFM flow sensors for Hot Liquor and Wort.

Brewhouse prices are indicative, and do not include control panel.


 4 Vessel Brew House



Mash Conversion Vessel

Fully Tig welded – no rivets – double skinned with 80-100mm insulation

With Mash mixing agitator

With Steam heating jackets


Lauter Tun

Fully Tig welded – no rivets – double skinned with 80mm insulation

With Lautering rake

With side mounted grain emptying door

With milled false bottom

With CIP spray ball.

With double glass liquid level.


Kettle

Fully Tig welded – no rivets – double skinned with 80-100mm insulation

Steam Heated with 2 jackets on the side and 1 on the bottom.

Top Glass manway with LED lighting


Whirlpool

Tangential inlets to initiate whirlpool and vortex breaker

Top Manway and LED lighting

Tubular heat exchanger available at extra cost.

brewhouse34

4vessel brewhouse system with brew pump

Also Includes:

Sanitary Brewing pump with speed control

Stainless steel transfer Plate Heat Exchanger on triclamp fittings

Non slip Work platform

Wort oxygenation and yeast adding tank.

Pt100 Temperature sensors on Mash, Kettle and Whirlpool

IFM flow sensors for Hot Liquor and Wort
