DGET-7BBL
DGET
8438400000
7bbl beer brewing equipment is typically applied to breweries that are much smaller than large-scale corporate breweries and are independently owned.Such breweries are generally characterized by their emphasis on flavor and brewing technique.The service includes: complete set of microbrewery equipment, installation turnkey, recipes and technology of branded beers, staff training and more.Microbrewery comes complete “turnkey” The performance of your Microbrewery, if necessary, can be increased in the future.
1-This system can meet beer mashing requrements, inclulding milling, mashing, lautering, boiling, whirlpool, cooling and so on.
2-All tonks were mode by SUS304, in accordance with the standard of food hygiene and safety stoandards.
3-The tank is equipped with variable frequency mixer which con ochieve the change of ootating speed from 0 to 50r/min and meet the requirements of rototing speed for mashing mixing and fltration tank mixing.
4-Automotic control or semi-automotic control wil design according with customer requirements.
5-Input and output of material and sel-circulation are connedted by sanitation pump and hose.Connedion type of pipelines for equipments is quick assembly which is convenient for deaning, maintenance and epair during produdion.
6-Resonable design, delicoted process, nice oppearance, durable service, easy for operotion, repair and mointenance.
Steam heating/electric heating/direct fire heating, you can choose according to your own needs.
Steam: Dimple plate jacket with inlet/outlet fittings for Steam heat transfer
Electric: Use electric heaters in jacket to heat the medium in the jacket
Direct fire: Use gas burner at bottom to heat tank directly
brewhouse details
Fermentation is the next step in the brewing process after the wort has been prepared.Fermentation tanks hold the wort while yeast converts to sugar in the wort into alcohol and carbon dioxide. These tanks should have a cone-shaped bottom, which facilities the process of recovering the yeast for later use.Jacketed fermenters allow you to control the mash temperature more easily.
4 stainless steel legs with leveling footpads
Interior shell: 304 stainless steel, thickness 3.0mm
Exterior shell: 304 stainless steel, thickness 2.0mm
Interior and exterior finish bright polish to 0.6μm, hygiene surface
Flanged and dished head top and bottom
20% headspace unless a different volume is requested
Combined drain extensions and beer port are standard
Top manway or side manway door
Dual zone in sidewall and bottom dimple cooling jacket with glycol inlet and outlet
Polyurethane insulation thickness 80mm for cooling jacket on side and bottom
Non welding CIP arm and rotating 360 degree reach spray ball
Carbonation system with micron stone
Solenoid valve, pressure relief valve (safe valve) are standard.
Pressure gauge
Temperature sensor
All clamps and gaskets to attach all accessories
fermentation tank accessories
7bbl beer brewing equipment is typically applied to breweries that are much smaller than large-scale corporate breweries and are independently owned.Such breweries are generally characterized by their emphasis on flavor and brewing technique.The service includes: complete set of microbrewery equipment, installation turnkey, recipes and technology of branded beers, staff training and more.Microbrewery comes complete “turnkey” The performance of your Microbrewery, if necessary, can be increased in the future.
1-This system can meet beer mashing requrements, inclulding milling, mashing, lautering, boiling, whirlpool, cooling and so on.
2-All tonks were mode by SUS304, in accordance with the standard of food hygiene and safety stoandards.
3-The tank is equipped with variable frequency mixer which con ochieve the change of ootating speed from 0 to 50r/min and meet the requirements of rototing speed for mashing mixing and fltration tank mixing.
4-Automotic control or semi-automotic control wil design according with customer requirements.
5-Input and output of material and sel-circulation are connedted by sanitation pump and hose.Connedion type of pipelines for equipments is quick assembly which is convenient for deaning, maintenance and epair during produdion.
6-Resonable design, delicoted process, nice oppearance, durable service, easy for operotion, repair and mointenance.
Steam heating/electric heating/direct fire heating, you can choose according to your own needs.
Steam: Dimple plate jacket with inlet/outlet fittings for Steam heat transfer
Electric: Use electric heaters in jacket to heat the medium in the jacket
Direct fire: Use gas burner at bottom to heat tank directly
brewhouse details
Fermentation is the next step in the brewing process after the wort has been prepared.Fermentation tanks hold the wort while yeast converts to sugar in the wort into alcohol and carbon dioxide. These tanks should have a cone-shaped bottom, which facilities the process of recovering the yeast for later use.Jacketed fermenters allow you to control the mash temperature more easily.
4 stainless steel legs with leveling footpads
Interior shell: 304 stainless steel, thickness 3.0mm
Exterior shell: 304 stainless steel, thickness 2.0mm
Interior and exterior finish bright polish to 0.6μm, hygiene surface
Flanged and dished head top and bottom
20% headspace unless a different volume is requested
Combined drain extensions and beer port are standard
Top manway or side manway door
Dual zone in sidewall and bottom dimple cooling jacket with glycol inlet and outlet
Polyurethane insulation thickness 80mm for cooling jacket on side and bottom
Non welding CIP arm and rotating 360 degree reach spray ball
Carbonation system with micron stone
Solenoid valve, pressure relief valve (safe valve) are standard.
Pressure gauge
Temperature sensor
All clamps and gaskets to attach all accessories
fermentation tank accessories
