DGET-5BBL
DGET
8438400000
Combination: mash/lauter tun+boiling/whirlpool tun
useful capacity: 5BBL
steam heated, electrical heated or direct fire heated
mash tun with mixer, steam jacket, VFD motor, insulated 80mm. Stainelsss steel 304.
lauter tun with rake system, milled false bottom, sparging spray ring,VFD motor, insulated 80mm.
boiling tun with steam jacket, inner heated option, insulated 80mm. Stainelsss steel 304.
whirlpool tun with Tangential whirlpool inlet. insulated 80mm. Stainelsss steel 304.
external grant, hops back, heat exchanger.Wort oxygenation system, working platform.
all the necessary pipelines and pumps.
the mash system is running
stainless steel plate heat exchanger
Capacity: +25% Head space
Interior shell thickness 3.0mm, Exterior shell:2.0mm
100% TIG welding with pure argon gas shield
Interior finish: pickled and passivated, external polished, 80mm insulated
Test pressure 3 bar, working pressure 1.5 bar
Glycol zones (Both on side and concial/bottom)
60°conical bottom for Fermener, top manhole
Racking arm, Sample valve, Pressure relief valve on the top, Dry hopping on the top
Mechanical relief valve 3 bar on CIP arm with pressure gauge
Adjustable tank leveling pads
Bright beer tanks are often also called serving tanks, bright beer tanks (=BBTs), maturation or conditioning tanks. We know that bright beer tank is the last vessel that beer comes in contact with to become a beer that is perfectly matured, clarified and ready to be packaged and served.
Depending on their application , the beer serving tanks can be glycol jacketed or can be located in a cold room. For brewpubs serving is often done by pumping or pressurizing the beer toward the serving location.
bright beer tank
304 stainless steel, 2B finish
Fixed stainless steel legs and bases with adjustable legs
Preformed dimple cooling jackets within cladding
Sanitary side mounted manway with pressured door
Stainless steel pressure/vacuum relief valve
Full sanitary metallic sealed sampling valve
Shell and bottom dome insulated and clad
Carbonation port and stone included
bright beer tank accessories
Customized name plates (with brewery name and logo)
Customized diameters/height
Several finishes available, including Brushed, 2B, 8K Mirror
If you are interested in DEGONG brewery equipment, get in touch with me freely.
