500L 1000L 2000L Customized Brewery Equipment Used 2/3 Vessel Beer Brewhouse with Steam/electric Heating Method

If you are just starting out with a micro-brewery or brewpub, our brewhouse offers a phased scale-up approach to get your taproom up now and your process setup for future distribution. You are in control of your design and our experts can help you refine it for the best outcomes.
DEGONG brewing systems offer superior performance at every phase, from reducing the overall brew time, increased wort clarity, and hop utilization to crank out delicious beer for decades.
Thickness of material (mm):
Insulation:
Heating method:
Construction:
Material:
Quantity:
  • DGET-500L 1000L 2000L
  • DGET
  • 8438400000


DEGONG BEER BREWHOUSE INTRODUCTION


DEGONG brewing systems offer superior performance at every phase, from reducing the overall brew time, increased wort clarity, and hop utilization to crank out delicious beer for decades.

If you are just starting out with a micro-brewery or brewpub, our brewhouse offers a phased scale-up approach to get your taproom up now and your process setup for future distribution. You are in control of your design and our experts can help you refine it for the best outcomes.

DEGONG beer brewhouse

1.Mash/Lauter tank

Mash Tun

Mashing is the mixing of wort and hot water so that an insoluble substance becomes soluble under the action of enzymes. The saccharification could be infusion mash or decoction mash.

Lauter Tun

Proper filtration is key to achieving the brew you desire. When the mash is pumped into the lauter tun, the sweet wort is then separated from the grain husks.The wort can then be transferred to the kettle while sparging removes any residual sugars to be collected. An adjustable height raking machine keeps the bed from collapsing allowing for a quick vorlauf and collection while maintaining your desired clarity.

3 vessel beer brewhouse


This mash tun and lauter tun hybrid combines two essential pieces of brewhouse equipment to create a vessel that operates in half the space of two unique machines.


Mash/lauter tank features

100% 304 stainless steel construction, including all non-product contact and structural steel

2B product contact material finish, with internal welds polished

Designed with adequate free board above the maximum working volume

Glass cover manway

Low chloride ceramic blanket insulation

Rotary sprayballs to clean vessel

Easy spent grain removal

Evenly distributed wort collection

Grist hydrator

false bottom with ≤0.7um filter aperture

beer lauter


beer mashing




2.Boiling/whirlppol

After filtration, the wort is boiled and sterilized. Hops are added during the boiling process to add flavor and bitterness to the beer.After boiling, the wort is transferred into a whirlpool to remove any protein present. During this stage, any malt or hop particles are removed to leave a liquid that is ready to be cooled, aerated, and fermented.

2-vessel beer brewhouse



Features

100% 304 stainless steel construction, including all non-product contact and structural steel

2B product contact material finish, with buffed internal welds

Designed with adequate free board above the maximum working volume for safe ingredient additions

Glass cover manway

Tangential inlet designed to achieve tight trub piles

Low chloride ceramic blanket insulation

Rotary sprayballs to clean vessel

beer brewhouse control


boiling





3.Hot water tank

Making beer requires the use of a lot of hot water, often at very specific temperatures. We use 'strike' water to soak or 'mash' grain at very specific temperatures to release sugars and then later use 'sparge' water to rinse off the sugars. This where the Hot Liquor Tank (or HLT) comes in.



RE:We also can choose 3 vessel beer brewhouse design, with a dedicated whirlpool vessel allows them to efficiently double batch a beer in a single day. By pushing the beer quickly out of the boil kettle into the whirlpool, where it is then knocked out, they are quickly able to get the second batch into the boil.



If you have interest in DEGONG brewing equipment,welcome to contact me freely.
