Stainless steel 2 station beer keg barrel washing/rinsing machine washer

The keg cleaning machine we supply has three type for customers option. One is with one cleaning head and one is with two cleaning head and the other is with four head.

Quantity:
  • DGET-KEG WASHER
  • DGET
  • 8438400000


Gerneral Introduction:

The keg cleaning machine we supply has three type for customers option. One is with one cleaning head and one is with two cleaning head and the other is with four head.

Kegs shall be placed manually inside the cleaning port which is on the work table in the status “bottom up” and is locked by a pneumatic plunger automatically. Then cleaning process begins. The cleaning procedures are automated and pneumatic valves were controlled automatically by a PLC. When the cleaning process finishes, the plunger will rise and the keg is to be unloaded from the work table manually.

The cleaner has two cleaning program. One is complete cleaning flows and the other is fast rinsing. For containing draft beer, strict sterile condition of kegs shall be guaranteed. So, complete cleaning process shall be required. For containing beer of fast consumption, simple rinsing will be suitable.


Keg cleaning machine:

Type:

- one-station keg rinser/cleaner

- two-station keg rinser/cleaner

-one-station keg filler

- two-station keg filler

- four-station keg filler


keg washer


keg washer3


2-Station 2-Tank Auto Keg Rinser








Double Station Two Tank Keg Rinser

Function: Keg rinsing

Model: HZQX-II

Rinsing Capacity: 40-60kegs/hr

Input Power: 0.75kwx2

Heating: Electric, Power: 15kw(steam  for optional)

Inversion rinsing

Kegs style: 5-50 liters with D=Φ250-Φ500mm H=360-600mm

Siemens programmable Controller

Automatically Washing, Sterilizing, and CO2 pressure preparation

Two Tanks: Alkali Tank, hot water tank

Sterilizer/Alkali Water Recycled

Pneumatic valve

Working Process: Start-Clean Water-Caustic Liquid-Hot Water-Hot Water-Steam Sterilization-CO2 Pressurization-Stop

Steam sterilization is user-selectable

Weight: 350kg

Dimensions: 1000x1600x2000mm




Keg Washer Specification

Carbon steel or stainless steel

Special designed for malt



Features:

(1) the capacity is 80-120kegs/hour;

(2) can be with electrical heating or steam heating or keg washer;

(3) can with all kinds of beer spears.





air source pressure

0.5~0.7Mpa

CO2 source pressure

0.4~0.6Mpa

cylinder valve pressure

0.4~0.5Mpa

CO2 valve pressure

0.2~0.25Mpa

Air-blow valve pressure

0.3-0.4Mpa

sterile water pressure

0.3Mpa

steam pressure

0.3-0.4Mpa
