| Composition |
Mash / Lauter Tank
Boiling / Whirlpool Tank
Stainless Steel Work Platform with Handrails
Fully Welded Sanitary Process Piping System
Complete Electrical Package
Fermentation tanks
Mash / Lauter Tank
54” inner diameter all stainless steel 304 construction, dished top and bottom.
Fully TIG welded assembly. Internal welds are smoothed with external welds acid cleaned and re-grained. External welds are stripe buffed.
Internal mash grid assembly with (4) wedge wire removable screens for ease of cleaning.
(1) 17” x 21” sealed access door.
(1) 16” sealed top man door access.
(1) Thermo-well installed with RTD for measuring temperature in Mash / Lauter Tank (Please note that we recommend a 42” Digital wand to measure multiple places in Mash / Lauter Tank to gauge an accurate temperature).
2” mineral wool insulation with 14 gauge polished stainless steel outer shell.
Boiling / Whirlpool Tank
44” inner diameter all stainless steel 304 construction, dished top and bottom.
Fully TIG welded assembly. Internal welds are smoothed with external welds acid cleaned and re-grained. External welds are stripe buffed.
(1) 16” sealed top man door access.
Internally mounted/removable trub dam.
Internally mounted ladder assembly for easy cleaning access.
Heating elements in the Boil Kettle
(1) Thermowell installed with RTD for measuring temperature in Brew Kettle.
4” diameter leg assembly with standard anchor pads.
2” mineral wool insulation with 14 gauge polished stainless steel outer shell.
| Contact us |
The special attention we give in the final quality inspection of each work is also a guarantee of unparalleled reliability and robustness. If you have any needs or questions, please contact us.
