| Material: | |
|---|---|
| Thickness of material (mm): | |
| Manhole: | |
| Quantity: | |
DEGT-500L
DEGT
8438400000
Function: Used for keep wort fermentation or maturation.
Standard stainless steel conical cylindrical fermentation tanks
Single, double, triple or more size as brewhouse is common used in commercial breweries
Tanks quantity is exactly calculated by fermentation cycle for various beers
Cooling method: dimple plate or glycol cooling jacket both bottom and top.
With all manhole, valves, pressure gauges, fittings etc.
Design pressure is 3bar; Working pressure is 1.5bar. (can be customized).
With CE,ISO,PED certificate
4 stainless steel legs with adjustable foot
Interior shell: 304 stainless steel, thickness 3.0mm
Exterior shell: 304 stainless steel, thickness 2.0mm
Interior and exterior finish bright polish to 0.6μm
60 degree cone bottom, other angles can be specified during the design process
Combined drain extensions and beer port in cone are standard
25% headspace, unless a different volume is requested
Top or side manhole
Dual zone in sidewall and cone dimple cooling jacket with glycol inlet and outlet
Polyurethane insulation thickness 80mm for cooling jacket on side and bottom
Fully welded exterior shell
Non welding CIP arm and rotating 360 degree spray ball
Ice water solenoid valve, pressure relief valve (safe valve) are standard
With Pressure gauge, Temperature probe,Sanitary sample valve,mechanical regulator valve,raking arm and port
All clamps and gaskets to attach all accessories
Tank complete with piping, fittings, sanitary valves and all parts.
Carbonation port is available for special request (stone not included)
Dry hop ports and/or hop bag hooks in any fermenter of any size for special request
We customized it for Italian customer
1-There is a dimple jacket to cool down. The inside of the jacket is filled with alcohol water. It can be used with temperature sensing and solenoid valve to maintain the temperature inside the tank.
2-With a breathing valve and a mechanical pressure regulating valve, the pressure of the tank can be maintained at a set value, and the safety hazard caused by thermal expansion and contraction during cleaning can be eliminated.
3-Top manhole,with lower cost ,simple processing,Easy cleaning and more sanitary.
Side manhole ,price little higher than top manhole,observe the beer in fermenter, when the height of the room is limited, we will choose side manhole.
4-60 to 90 degrees bottom cone can adjustable.its according to the container height for shipping , save much shipping cost for client.
bottom cone, 360 degree cleaning ball, sight glass, raking arm
fermentation tank details drawing
If you have interest, please feel free contact with me.
