DEGT-1200L
DEGT
8438400000
DEGT beer brewery equipment Fermenter tank made of high quality stainless steel, using dished head, cylindrical tank, 60° cone bottom, Maitreya honeycomb punching jacket welding, refrigerant inlet and outlet, safety valve, sampling valve, temperature control, sanitary manhole, CIP cleaning Interface, wort import, yeast export, which can meet the various process needs of craft beer.
1. A conical fermenter allows for the fermentating and the aging/storing of the brewing process to occur in the same tank. The cone bottom collects the sediment which is then easily removed by slowly opening a bottom valve until the liquid runs clear, leaving the beer to age.
2. For this reason they are often referred to as "Uni-Tanks" as opposed to their flat-bottom counterparts that require transferring beer to a secondary conditioning tank to separate the sediment.
3. Modern commercial conical fermenters have the advantage of being made from stainless steel which can be reused indefinitely, is impregnable to odors and discoloration, and can be sanitized easily. Most jacketed fermenters sit atop legs and thus allow siphoning to occur through gravity. Additionally, yeast can be drawn off at any point during fermenting, to be washed and reused again.
4. These features yield considerable cost and time savings for commercial breweries, as well as faster turn-over rates for batches. Glycol-jacketed fermenters have the added benefit of an efficient cooling system built right into the tank.
Interior Shell: SUS304 full welded; TH=3mm
Exterior Shell:SUS304 full welded; TH=2mm
100% TIG welding with pure argon gas shield
Interior Finish: Overall polishing to 0.6 μm without dead corner
Insulation: Polyurethane; TH=100mm
Glycol Jacket: Dimpled plate on cone and sid
Dished head and 60 degree cone bottom
CIP arm with 360° coverage CIP spraying ball
Rotating racking arm and port on cone with butterfly valve
Tri clamp discharge arm with butterfly valve
Thermowell for high accuracy temperature sensor
3pcs completely SUS304 heavy duty legs with leveling pad and legs support
Complete valves, fittings and all parts
Level tube for special request
Carbonation port and stone for special request
Customized fermentation tank for Italian customer
If you are interested in beer brewery equipment, please contact with me.Thanks!
