DEGT-800L
DEGT
8438400000
Equipment for microbrewery is typically applied to breweries that are much smaller than large-scale corporate breweries and are independently owned, but larger than breweries for restaurant, bars etc., as it distributes beer to local restaurants and bars, parties etc. To run a micro brewery and get suitable margin from this kind of business model, we suggest to start from 1000L/brew capacity minimum that concerning both the budget limitation and expanding capacity in future. Also 2000L-3000L beer equipment are common to see for a little larger business.
The equipment for microbrewery is more professionally functional and concerns more details to brew in a more smart way, trying to decreasing the factors that may affect the brewing speed or beer flavors.
| Main brewing system | Components | Main specification |
| Mill system | malt miller machine grist case | |
Brewhouse | Mash/lauter/whirlpool | 800L 25% head space, Steam heating with insulation False bottom, Rake&motor, Spent grain outlet CIP, sight glass. Tangential inlet |
| Kettle | 800L 30% head space, Steam heating with insulation Steam condenser, Wort outlet and trub outlet | |
wort pump Hot liquor pump | 3T/hr, Sanitary | |
| work platform | Disassemble, Adjustable | |
| PHE | Two stages Connected with wort aeration device Disassemble | |
| Fermentation | Fermentation tank | 25% head space, Jacketed and insulated Conical bottom, Pressure valve, relief valve CO2 relief valve Coolant inlet and outlet Sample valve Side manway Top, Dry Hopping Port CIP connections Wort inlet and yeast outlet Racking arm Temperature and pressure gauges |
| Bright beer tank | 20% head space, Jacketed and insulated Dished head&bottom Pressure valve, relief valve Site Glass level Carbonation stone assembly Sample valve Side manway Fill/drainage port CIP connections Temperature and pressure gauges Jacketed and single wall tanks | |
| Cooling | Glycol cooling tank | Thermowell Top manway CIP arm and spray ball 360 degree of coverage |
| Chiller | ||
| Controling | Mashing control | Mixing, rotation, wort pump |
| Fermenting control | Temperature, pressure, lamp | |
| Cooling control | Machine unit, pump,temperature | |
| Cleaning | Alkali tank | 50L ss304, thickness:2mm,welds grinded to Ra 0.6μm |
| Sterilization tank |
1.Appearance clean and generous and the equipment is bright;
2. Good insulation effect,the equipment is divided into two kinds of heat insulation and cold insulation, which is the best to ensure the temperature of the beer brewing process;
3. Low energy consumption: environmental protection, energy saving, low powerconsumption.
1.DEGT is a professional company of beer brewery equipment ,nearly 10 years of beer equipment manufacturing history（ including Production→ Inspection→ Packing & Shipping→ Installation &Training → After Sales）will do its best to meet the needs of customers in all regions.Since the establishment of the company, it has been well received by numerous customers.
2.These products enable systematic execution of milling, mashing, fermentation, filtration, filling and other related processes.Before bringing these products to market, we rigorously test on each system to ensure that each brewing system is intact.
3.Attention to detail at every step.We provide one-stop services from one concept to a real product , and we can offer you very competitive prices
4.Strong productivity of kinds vessels, we can produce satisfied product according your design.
If you have needs for craft brewing equipment, please feel free to contact us,my pleasure. Please leave messsage in below to get our latest quote and equipment list for beer filter or turnkey brewery.
