5HL Microbrewery Equipment Easy Installation Flexible Small Beer Brewing System in Brewpub/bar/restaurant

Small craft brewery is more used for brewpubs or customers who wants to make smaller breweries.The size range from 300L to 1000l, or 3BBL to 10BBL, with flexible heating method, which includes electric, gas and steam heating. We do the system based on existing building, the total layout following exact building requirement, the principle is making full use of the space. The goal is helping the hobby brewers who wants get into beer business with good and reasonable solution and using the brewery system for easy and simple brewing. Making the system combined well with your existing brewing knowledge.

• Brewpub Nano Beer Brewing kit

• Restaurant Nano Beer Brewing System

• Hotel Nano Beer Brewing System

We design and produce a line of nano brewing equipment according to your specifications. To guarantee breweries'reliable performance, we use qualified stainless steel, fittings, and various parts, with our good craftsmanship, rich experience and technology in brewing industry. Especially, we focus on your convenient running procedures, by learning your special specifications and realizing them on the brewing systems.

—1. Malt Milling Unit

Function: It is used for malt milling.It is the first part of beer brewing equipment.

Component: Malt miller, belt, belt pulley, motor, and so on.

Material: Carbon steel or stainless steel for optional.

Flexible or steel auger or a bucket type conveyor to directly lift the milled grain to mash tun

—2. Malt mashing system

Function:It is used for malt mashing.The water and the crushed malt are fully mixed, and the soluble substances in the malt are thoroughly leached under the action of various enzymes

Component:mash tank,lauter tank,boiling tank and whirlpool tank(The four tanks can be combined into 2 or 3 or 4 vessels ),wort pump,plate heat exchanger,hops filter,operation platform,aeration device.

Material:SUS304/316/Copper

—3.Fermentation system

Function:The wort obtained during saccharification is fermented into beer under the function of yeast.

Component:Fermentation tank,bright beer tank,yeast adding tank

Material:SUS304/316

Accessories on tank:breathing valve,hops adding port,CIP arm,CIP ball,pressure gauge,mechanical regulation valve,sample valve,carbonation stone,temperature sensor.....

 — 4.Cooling Unit

Insulated glycol water tank with or without copper coil for glycol liquid holding and mixing

Efficiency chillers or refrigerators with fryon to supply cooling energy

Sanitary centrifugal pump for glycol water recycle among tanks and heat exchanger

All pipes, fitting, insulation materials are included

—5. Controlling Unit

Electrical controlling cabinet with temperature, on-off controlling for brewhouse

Electrical controlling cabinet with temperature, on-off controlling for cooling parts

Temperature controller, thermocouple, solenoid valves etc are included

PLC with touch screen panel for special request

—6. Beer Dispense

Semiauto or automatic bottling machine with rinsing, filling, capping, labeling etc

Semiauto or automatic canning machine

Flash pasteurizer or tunnel pasteurizer is available

—7. Cleaning Unit

Function: Used for cleaning and washing.

Component: Disinfection tank, Alkali tank (with heating element), cleaning pump and etc. It is the seventh part of beer brewing equipment.

Purpose: Equipped with wheel, easy to move and operate, washing all tanks when it finishing brewing.

— 8.Other Facilities

Steam boiler for brewhouse heating

Water treatment for brew water

Oil free air compressor

Brewery lab instruments for beer quality test

If you have interest in DEGONG brewing equipment,welcome to contact me freely.
