5BBL to 20BBL 2 vessel brewhouse system Two-vessel mash lauter and boiling whirlpool tanks

Two-vessel brewhouse mostly in the volume from 5BBL to 20BBL,which is suitable for a brewpub or tap room.The vessels,process,volume and configuration are custom-designed to satisfy the client usage and fit the client site.Two-vessel brewhouse is most widely commercial-used and with high performance-price ratio.
Thickness of material (mm):
Heating method:
Insulation:
Quantity:
  • DGET-10BBL
  • DEGONG
  • 8438400000
Brewing system Product Description

Two-vessel brewhouse mostly in the volume from 5BBL to 20BBL,which is suitable for a brewpub or tap room.The vessels,process,volume and configuration are custom-designed to satisfy the client usage and fit the client site.Two-vessel brewhouse is most widely commercial-used and with high performance-price ratio.



The system can be heated by steam,electricity or gas;and controlled by manual,semi-automatic or full automatic;and equipped with rake system or not.The mainstream of two-vessel brewhouse is steam heated and semi-automatic controlled system,and equipped with rake system when working volume is no less than 5BBL.

Standard configuration for 2-vessel brewhouse system includes 2 brewhouse vessels:mash/lauter tun combined and kettle/whirlpool combined vessel,work platform,and S.S.sanitary piping and control system.


brewhouse2-min

Brewing brewhouse system

Mash/lauter tun typical features:

  • Top manway,waterproof light on the top,CIP spray ball,top sparging system,port for grist hydrator,vapor vent port,gear drive and rake system

  • False bottom removal slot,thermowell port,wort recycle with adjustable vorlauf arm,rectangular side manway with manway cover for spent grain-out

  • Wort out collector,milling false bottom,false bottom under-flush assembly with spray nozzles,spent grain-out port



Kettle/whirlpool combined vessel typical features:

  • Top manway,waterproof light on the top,CIP spray ball,top sparging system,vapor vent port on the top;

  • Tangential whirling port,side steam jackets(or flange coupler for heat element for electrical kettle),thermowell port,

  • Upper and lower wort out ports on hollow dish bottom,bottom steam jackets,and slope flat bottom for gas kettle and electrical kettle.

  • Piping system includes all internal connected pipes for the brewhouse,i.e.:wort piping,sparging piping and CIP piping;also includes the necessary functional assemblies,such like liquor blending system with flow meter,and wort aeration with sterile air filter;and the auxiliary equipment,such like wort pump(s)and heat exchanger;and all fitting,valves and devices in the pipes.Brewhouse pipes material is 304 sanitary stainless steel.

  • Semi-automatic control system includes the control panel,VFD,RTD and wiring.


 Brewing system detail shows



brewhouse Pipelines-min

Wort pumps and pipelines


polish details-min

Top manway glass


spent grains access-min

Manway for spent grain-out


large sight glass-min

Sight galss and ergonomic platform
