10BBL craft commercial stainless steel beer brewery equipment with insulation

Beer Brewery Production Equipment is available from 1BBL to 20BBL with an average 25% Head Space. The 10BBL beer brewery equipment can  be instelled in restaurant, brewery,beer bar,hotal etc.  Working with all relevant partners, DEGONG can manage the design, engineering, build and installation of a brewhouse that helps you achieve your unique brewing process and replicate it. In the end you will have a long-term, sustainable commercial beer brewing system that maximizes efficiency and space.

• 300-500kg/h

• Doubel roller

• Nosie: 45db or so

• Mash/Lauter tun

• Kettle/whirlpool tun

• Steam heating method

• Hot water tank

• Tubular glass level indicator

• Tangential wort inlet

• Side mounted grain outdoor with grain chute

• Laser cutting V-wire False Bottom

• Heating exchanger: 10 square meters

• Wort pump: ABB motor, VFD control

• Wort aeration device

• Yeast adding tank

• Seamless food grade stainless steel 304 pipes

• Working platform

Technical Parameters

Grain raker&cleaning ball&polishing treatment

• Beer fermenters

• Bright beer tanks

• Yeast adding tank

• Accessories, such as sample valve, pressure gauge, safety valve and so on

Technical Parameter

• Material Inner (SUS304)thickness: 3.0mm; Outer(SUS304)thickness:2.0mm

• External-Jacket(SUS304) thickness: 1.5mm;

• Oval head cone bottom, thickness: 3.0mm.

• Surface: Finish2B – cold-rolled, annealed, pickled

• Inner surface treatment: welds grind to Ra 0.6μm (attached 360 degree Omni cleaning ball).

• Mirror surface finish inside.

• 100% TIG welding with pure argon gas shield

• Insulation: Polyurethane-thickness 100 mm.

• Equipment with : cone 60°resist compression design,dripping 10.Temperature drop.

• Cleaning System: All-round cleaning

• Vessel Pressure: test pressure 3 bar, working pressure 1.5 bar

accesorries of  fermenter

CIP system is generally consisted of 2 tanks which are separately sanitary tank are alkali tank. For most micro brewery equipment, CIP system is with 4 wheels at the bottom of platform so it is removable. There is also a washing pump so that the mixture liquid or sole liquid can be transferred to clean tanks.

CIP system

Cooling system is always consisted of circulation pump, glycol water tank and chiller.

Features and parameters

• Stainless steel(304)sanitary construction

• Inner (SUS304)thickness: 3.0mm; Outer(SUS304)thickness:2.0mm

• External-Jacket(SUS304) thickness: 1.5mm

• 100% TIG welded and sanitary polished

• Design pressure 0.3 MPa, working pressure <0.2 MPa.

• Interior Finish: Sanitary 2B finish, Pickled and Passivity;

• 4 heavy duty stainless steel legs with adjustable height and leveling footpads

• Insulation: Polyurethane-thickness 100 mm.

• CIP arm and spray ball 360^o coverage. Easy clean slide over pipe connection with keeper pin.

• Pressure gauge

• Thermometer gauge

• Lifting lugs

• Side man way door

Control system is the soul of a whole set of brewery equipment. It controls the running of each components such as pump, motor and whole brewery system. Degong’s control system is a integrated box which houses the terminals of all components.

control cabinet

Standard packing:

Cord ,film membrane

Firm membrane, wood box for free fumigation

Transport: by sea

Delivery :

     - We put your order into our tight production schedule to ensure the punctual delivery time.

     - Production or inspection report before your order packed.

     - Shipping notice/ insurance to you as soon as your order is shipped.

All of the productions we provided are certified by ISO,CE and TUV. The quality, specification and function all meet the treaty of contract.

Every beer brewery equipment is unique and requires different specifications. Please shoot us an email or give us a call for a quote.
