1000L/10BBL commercial brewery fermentation tanks/CCT/uni-tanks customizable for brewing craft beer

DGET is an experienced supplier of fermentation tanks for biogas systems that are being constructed or expanded. Over the years, we have built numerous tanks and focused in particular on fermenters.
we use the best structural materials in order to guarantee a long lifespan and low maintenance costs.

capacity:
Material:
Thickness of material (mm):
Quantity:
  • DGET-1000L
  • DGET
  • 8438400000

DGET is an experienced supplier of fermentation tanks for brewery systems that are being constructed or expanded. Over the years, we have built numerous tanks and focused in particular on fermenters.

we use the best structural materials in order to guarantee a long lifespan and low maintenance costs.


fermentation tanks01-min

1000L fermentation tanks for sale


Fermentation system features:

fermentation tanks2min

Brewery fermentation tanks available


Function: Used for keep wort fermentation or maturation.

  • Standard stainless steel conical cylindrical fermentation tanks

  • Tanks quantity is exactly calculated by fermentation cycle for various beers

  • Cooling method: dimple plate or glycol cooling jacket both bottom and top.

  • All manhole, valves, pressure gauges, fittings etc are included



发酵罐细节-min

Fermentation tank processing details, etc.

Beer fermentation tank is also called CCT, fermenters are made of SUS 304, for fermentation and maturation of beer. We design, manufacture all variety fermenters from 100L to 30000L . With all the necessary valves, connections, microbrewery fermenters are the CE certification.


cleaning ball and thermometer-min

Spray ball;thermometer couple


racking arm-min

Welding and raking arm

Related components in the fermentor:


Safety valve This special overpressure relief valve is designed to protect the tank against overpressure by a pressure higher than that for which it is certified and dimensioned. The overpressure relief valve is most often combined with a vacuum relief valve that protects the tank from collapse under vacuum (for example, when the tank contents are drained out using the pump).
Vacuum valve it protects the tank from collapse under vacuum (for example, when the content is drained out with a pump).
Sample valve it is used for sampling the product during its tasting and laboratory tests.
Temperature sensor  the socket is a small tube welded on the side of the tank for insert the thermocouple of the control system, or thermometer for visual temperature measurement.
PU insulation The tank is usually insulated with a polyurethane foam (optionally with other insulating material) that fills the space between the inner jacket and the outer shell of the tank. Usually, we only isolate only both the cylindrical and conical parts of the tank.
Dimple cooling jacket Cooling the tank is done with liquid which flows in double jacket of the tanks (most commonly a glycol water is used).



Optional:

  • volume of tank ( volume, diameter, height), specifically designed according to local conditions

  • working pressure: 1,2 bar to 3 bar

  • manhole position: top, side, bottom cone

  • thermal insulation: 70/80/100 mm polyurethane foam

  • cover: pickled, brushed, polished

  • no. of thermal sensors

  • fermentation controller: with CO2 outlet, w/o CO2 outlet

  • level measure: w/o level measuring, mounted with instrument for measure

  • type of cleaning head: static, rotary

cold water tank and chiller-min

Glycol tank and chiller used to cool the fermentation tank


Our services:

Quality control:

  • All stainless steel coils are purchased from high-quality steel supplier.All chemical composition and mechanics performances are controlled strictly.

  • All welders are qualified.

  • ISO9001 system assures all procedures done correctly.

  • All tanks are inspected completely before delivery


装载2-min


After-sales Service Provided:

  • 2 years of tank and 6 months of accessories guarantee, lifelong maintenance at cost charge

  • 7x24 hours per week email&phone available

  • Maintenance, return & exchanges services

webp-min
