DGET-5000L
DGET
8438400000
| Commercial beer brewing equipment DEGONG MANUFACTURER |
Brewing beer system
From small batch microbrewery equipment to 50,000 fermenters. Find everything you need to fit your brewery from our expansive inventory.
Brewing equipment— Brewhouse system | |
| Mash & Lauter Tank | Inner(SUS304),thickness:3.0mm; External-Jacket (Stainless steel), thickness: 1.5mm; Cylinder (sharp type, SUS), thickness: 1.5mm. Inner surface treatment: welds grinded to Ra 0.6µm. Insulation: Polyurethane-thickness 100 mm. |
| Boiling &Whirlpool Tank | |
| Hot Liquor tank | |
| Mill machine | 500Kg/h;Power: 2.2kw, voltage:380V |
| Water treatment | 1000kg/h;water pump power:1.5kw |
| Steam generator | 500kg/h;Steam temperature: 170°C |
| Wort pump | 5000L/h;Power:1.5KW, lift:24m, Rev:2880r/min |
| Plate Heat exchanger | 50m2;exchange board material SS304 |
| Pipeline & Valve VLV | SUS304 ;single surface weld & double surface forming, no dead angle |
| Wort measuring meter | Stainless steel |
| Venturi tubes | Stainless steel |
| Saccharometer | Glass |
| Rake | SUS304 Rake |
| Operation platform | Stainless steel |
| Brewing equipment—Fermentation system | |
| Fermentation tank | Inner(SUS304),3mm; Jacket 1.5mm;welds grinded to Ra 0.4µm (attached cleaning ball); Polyurethane-thickness 100 mm;cone 60°resist design |
| Yeast adding tank | Stainless steel 304 |
| Food tube | Include tube Joints and hose hoops |
| Refrigerant pipelines | PPR/ Stainless steel |
| Keep warm tube | polyethylene 100mm |
| Cooling system | |
| Glycol tank | Material: Inner(SUS304),thickness:2.5mm;External-Jacket(Stainless steel); Insulation: Polyurethane-thickness 80 mm. |
| Refrigerating unit | medium:Freon 404 |
| Circulate pump | 1-2pcs |
| Pipeline& Valves | PPR/ Stainless steel |
| Control system | |
| Mashing control | Methods:Semi-automatic control; Full-automatic control (PLC) |
| Fermenting control | |
| Cooling control | |
| Cleaning control | |
| Cleaning system (CIP) | |
| Washing pump | Stainless steel |
| Alkali tank | Stainless steel |
| Sterilization tank | Stainless steel materail |
CIP Station for cleaning tank after each batch is brewed
Linear mashing brewing system
Fermentation tanks side/top manhole with double wall and cooling jacket
| Contact Alice today |
Microbrewing, craft brewing or commercial large brewhouses, we have the equipment, supplies & install engineers. Looking to find bottling lines and tanks for sale we have that covered.
