Beer Brewery Unit 1000L Fermenter Storage Tank CCT Beer Fermentation Complete Fermentation Sets for Sale

1000L SUS304 Fermenter description

• Material: SUS 304/316 AISI304

• Volume: 1000L Efficient, 1250L total volume, 30% clearance at the top not counting the arched top.

• Doomed top, 60 degree conical bottom.

• Double layer with cooling jacket.

• Working pressure: 2 bar. Tested up to 3 bar.

• Inner tank thickness: 4mm, outer garment: 2mm.

• Insulation of polyurethane, thickness: 100mm, sides and bottom are insulated.

• The cooling cap is welded in points to the tank.

• 2 cooling zones controlled separately: cylinder and conical base.

• Exterior: Polished.

• Internally polished, all welding surfaces are polished and cleaned with acid.

• Roughness: 0.4 um

• 4 stainless steel legs with adjustable feet. Option: Wheel.

• At the top: CIP arm, Sprayball, combined pressure and suppression valve (PVRV), hobport  (blind plate with 4″ triclamp).

• Option: Butterfly valve on the entrance for dry hop.

• On the side: Glycol Inlet and outlet, thermo sensor and sampling port.

• Manhole in the top or side of your choice.

• At the bottom: drain valve, beer outlet, racking arm, carbonantion device and thermo sensor.

• CIP arm included Steam gauge.

• Mechanical pressure valve mounted on CIP arm.

• Prepared for half batches.

• Input and output for glycol cooling

• solenoid valve to control glycol.

If you are interested in DEGONG beer brewery equipment, please feel free to contact me.
