DGET-400L
DGET
8438400000
1.Automatic /semi-automatic operation system
2.With our equipment you can make different kinds beer such as ale,lager, IPA, stout beer and so on, we supply the brewing recipes
3.We have different capacity from 50L to 10000L per batch, our brewery equipment approved Pessure CE, ISO ,TUV certificate
4.Have good feedback from our clients
5.Installation/Operation/ Service/ Maintenance Manual: Provided In English.
6.Appearance clean and generous: The tank is polished by pickling and passivating, and the equipment is bright;
7.Good insulation effect: The equipment is divided into heat insulation and cold insulation, which is the best to ensure the temperature of the beer brewing process
8.Low energy consumption: environmental protection, energy saving, low power consumption, saving energy consumption of about 30%.
1. About the raw material:
About the sanitary stainless steel 304 , we use 3mm interior shell and 2mm exterior shell.
2. About the drawing:
Generally our technician will design the suitable layout accordingly before production once our customers confirmed their orders.Then our workshop will do the manufacturing strictly according to the detailed drawing.
3. About the welding and polishing:
We make sure the 100% TIG welding with pure argon gas shield. We use the central system of argon, instead of ordinary gas cylinder.The argon will help to reduce the oxygenation. After welding, they will be polished to arrive to 0.4 μm without dead corner firstly, then do acid pickling and passivation.Which will help to remove the oxygenation on welding line; and form protection film on the steel to avoid rust. It will help you to extend the tanks life time.
a complete of beer brewery equipment
inner wall stainless steel 304, 3mm;
surface wall stainless steel 304, or red copper, 2mm
Dome top,top manway with glass
Side manway, insulation: polyurethane 80mm;
raking agitator, removable false bottom
sparging arm, sight glass
Thermowell for temperature sensor and thermometer....
the mashing system is preparing wort
Inner wall stainless steel 304, 3.0mm
surface wall stainless steel 304, 2.0mm
Dome top, conical bottom,
Top manway or side manhole
Insulation: polyurethane 80mm
Glycol cooling jackets on both cylinder and cone
Inside 360 degree rotating CIP washing ball
CIP arm, Pressure gauge
safety&vacuum valve on top
sample valve, rotating racking arm
thermometer, carbonation stone (optional)
100% TIG welding with pure argon gas shield
Interior Finish: Mirror polishing to 0.4~0.6μm without dead corner
Testing pressure: 3 bar
working pressure: 1.5bar
fermenter in restaurant
conical fermenter details
We have more kinds Beer Brewing Equipment in different use, if you need, please contact us, so we can help you select the right system to meet your needs and fit your budget!
