Craft brewers are passionately committed to making the highest quality beer they can. The magic happens in the brewery itself, and in many ways, the building defines the brewery. The brewery must fit your space and growing needs as a brewer and there are many important factors to consider when selecting the right space to open your brewery.
we understand that a brewery is not just a financial investment, but an investment in yourself and your passion for craft beer. There are many important decisions to make and we want to give you the knowledge you need to make smart choices and set your brewery up for success.
| Thickness of material (mm): | |
|---|---|
| Insulation: | |
| Material: | |
| Heating method: | |
| Quantity: | |
7bbl beer brewing equipment produced by us. the brewhouse equipment for the production of live and filtered beer, brew master make their beer attractive to customers by unique brewing process and distinctive beer taster. If desired, they can be placed directly in places of consumption of beer: restaurants, pub, bars, hotels, tourist and shopping centers.
| Brewing system | Component | Specification |
| Grain Milling System | Rolling Miller Flexible Auger | Double roller Speed differential Stainless steel screw SUS304 |
Brewhouse system | mash/lauter tun | Steam jacket on bottom and side Agitator inside Wort hydrator mounted top of mash tun Grain rake with VFD Laser cutting V-wire False Bottom Easy clean and detachable sparging spray ring Multihole wort collect ring(optional) |
| boiling/whirlpool tun | Steam Jacket on bottom and side Steam vent with condensate ring for kettle stack | |
| Heating method | steam/electric/direct fire heating | |
| Fermentation system | Fermentation tank | Glycol cooling jacket on cone and bottom Side or top manway CIP arm and CO2 blow off arm Mechanical relief valve Shockproof pressure gauge Rotating racking arm Dry hopping port Carbonation stone Sight level |
| Yeast adding tank | stainless steel 304 | |
| Cooling system | glycol water tank chiller | Insulated conical top and sloped bottom Dimple plate on side wall |
| Cleaning system | Sterilization Tank Alkali tank | electric heating element inside SUS304 full welded |
| Control system | mashing and fermentation process control | Manual/Semi-automatic/Automatic PLC control with touch screen for special |
If you are interested in beer equipment, please feel free to contact me.
