500L-1000L Single Wall Double Wall Sus304/316 Fermentation Tank To Beer Fermenter for Sale

Production brief introduction

Fermenter made of high quality stainless steel, using dished head, cylindrical tank, 60° cone bottom, Maitreya honeycomb punching jacket welding, refrigerant inlet and outlet, safety valve, sampling valve, temperature control, sanitary manhole, CIP cleaning Interface, wort import, yeast export, which can meet the various process needs of craft beer.

Dished Head:

One CIP Spray Ball, 1.5” Tri-Calmp Connection

One Pressure Vacuum Relief Valve, 2” Tri-Clamp Connection

One Hops Adding Hole, 4" Tri-Clamp connection

Sidewall:

One Shadow Less Manway

One Temperature Sensor(PT-100) in Thermowell,

One Sample Valve, 1.5” Tri-Clamp Connection

One Pressure Gauge & Pressure Regulation Valve assembly on the side CIP arms, 1.5” Tri-Clamp Connection

One Cooling Jacket Sections

Connection for Glycol Inlet & Outlet

Glycol pipes in the tank insulation

60° Cone Bottom Head

One Yeast Discharge, 3”-1.5” Tri-Clamp connection

One Racking Arm, 1.5” Tri-Calmp Connection

One Cooling Jacket Section,

Connection for Glycol Inlet & Outlet

Vessel Specifications:

Approximate Inside Cylinder Dimensions: depend on equipment

Approximate Overall Outside Dimensions:depend on equipment

Approximate Weight: depend on equipment

80-100mm PU-Foam Insulation

Head Space, 33%

Vertical Orientation

Material, 304 Stainless Steel

Inside Finish, 2B

Outside Finish, #4

Picked and Passivated Surface and Seam

Internal & Exterior Welds, Grounded and Polished to #4

Four Adjustable Legs

fermenter with wheel: easy to move tank

 interior of fermentation tank

If you have interest, please feel free to contact me.
